At Aulone, we provide high-performance wire rope designed to meet the demanding needs of industries like construction, mining, marine, and transportation. Our ropes are built for heavy loads, tough environments, and critical applications, ensuring reliability and safety.
Round Strand Wire Rope | |||||||
| Rope Type | Typical Construction | Rope Diameter(mm) | Rope Type | Typical Construction | Rope Diameter(mm) | ||
| Wire Rope | Strand | Wire Rope | Strand | ||||
| Single-strand wire rope | 1×7 | （1+6） | 6~16 | 6×24 | 6×24S | (FC+12+12) | 14~44 |
| 1×19 | （1+6+12） | 10~30 | 6×24W | (FC+8+8/8) | 14~44 | ||
| 1×37 | （1+6+12+18） | 14~42 | 8×19 | 8×19S | (1+9+9) | 16~50 | |
| 1×61 | （1+6+12+18+24） | 20~54 | 8×19W | (1+6+6/6) | 16~50 | ||
| 1×91 | （1+6+12+18+24+30） | 30~66 | 8×25Fi | (1+6+6F+12) | 18~56 | ||
| 1×127~1×631 | — | 50~160 | 8×26WS | (1+5+5/5+10) | 16~54 | ||
| 6×7 | 6×7 | （1+6） | 6~36 | 8×31WS | (1+6+6/6+12) | 16~60 | |
| 6×19(a) | 6×19S | (1+9+9) | 12~42 | 8×37(a) | 8×36WS | (1+7+7/7+14) | 18~108 |
| 6×19W | (1+6+6/6) | 12~42 | 8×41WS | (1+8+8/8+16) | 28~120 | ||
| 6×25Fi | (1+6+6F+12) | 16~42 | 8×49SWS | (1+8+8+8/8+16) | 40~120 | ||
| 6×26WS | (1+5+5/5+10) | 16~42 | 8×55SWS | (1+9+9+9/9+18) | 40~124 | ||
| 6×31WS | (1+6+6/6+12) | 18~42 | 8×37(b) | 8×37 | (1+6+12+18) | 60~86 | |
| 6×19(b) | 6×19 | (1+6+12) | 9~46 | 8×61(a) | 8×61FWS | (1+5+5F+10+10/10+20) | 60~136 |
| 6×37(a) | 6×29Fi | (1+7+7F+14) | 18~64 | 8×64SFS | (1+9+9+9F+18+18) | 60~124 | |
| 6×36WS | (1+7+7/7+14) | 16~90 | 8×61(ab) | 8×65FNS | (1+6+6F+12-20+20) | 60~140 | |
| 6×41WS | (1+8+8/8+16) | 38~100 | 8×80WSNS | (1+7+7/7+14-22+22) | 50~158 | ||
| 6×49SWS | (1+8+8+8/8+16) | 38~100 | 8×84WSNS | (1+7+7/7+14-24+24) | 60~172 | ||
| 6×55SWS | (1+9+9+9/9+18) | 38~100 | 8×91(ab) | 8×111SWSNS | (1+9+9+9/9+18-28+28 | 60~156 | |
| 6×37WS | (1+6+15+15) | 16~64 | 8×103FSNS | (1+7+7F+14+14-30+30) | 60~190 | ||
| 6×37(b) | 6×37 | (1+6+12+18) | 13~66 | 8×109SWSNS | (1+8+8+8/8+16-30+30) | 60~190 | |
| 6×61(a) | 6×61FWS | (1+5+5F+10+10/10+20) | 60~110 | 8×61(b) | 8×61 | (1+6+12+18+24) | 60~134 |
| 6×64FS | (1+9+9+9F+18+18) | 60~100 | 18×7 | 17×7 | (1+6) | 12~44 | |
| 6×61(ab) | 6×65FNS | (1+6+6F+12-20+20) | 60~116 | 18×7 | (1+6) | 12~55 | |
| 6×80WSNS | (1+7+7/7+14-22+22) | 60~130 | 18×19 | 18×19S | (1+9+9) | 18~50 | |
| 6×84WSNS | (1+7+7/7+14-24+24) | 60~142 | 18×19W | (1+6+6/6) | 14~50 | ||
| 6×91(ab) | 6×111SWSNS | (1+9+9+9/9+18-28+28) | 60~128 | 18×19 | (1+6+12) | 14~50 | |
| 6×103FSNS | (1+7+7F+14+14-30+30) | 60~156 | 34×7 | 34×7 | (1+6) | 16~60 | |
| 6×109SWSNS | (1+8+8+8/8+16-30+30) | 60~156 | 36×7 | (1+6) | 16~60 | ||
| 6×61(b) | 6×61 | (1+6+12+18+24) | 40~110 | 35W×7 | 35W×7 | (1+6) | 16~60 |
| 6×12 | 6×12 | (FC+12) | 8~32 | 24W×7 | (1+6) | 16~50 | |
| 6×24 | 6×24 | (FC+9+15) | 30~46 | ||||
Shaped Strand Wire Rope | |||||||
| Rope Type | Typical Construction | Rope Diameter(mm) | Rope Type | Typical Construction | Rope Diameter(mm) | ||
| Wire Rope | Strand | Wire Rope | Strand | ||||
| 4V×39 | 4V×39S | (FC+9+15+15) | 14~46 | 6V×19 | 6V×30 | (6+12+12) | 22~38 |
| 4V×48S | (FC+12+18+18) | 20~50 | 6V×34 | (/1×7+3/+12+12) | 28~44 | ||
| 6V×7 | 6V×19 | (/1×7+3/+9) | 20~36 | 6V×37 | 6V×37 | (/1×7+3/+12+15) | 32~52 |
| 6V×19 | 6V×21 | (FC+9+12) | 18~36 | 6V×37S | (/1×7+3/+12+15) | 32~52 | |
| 6V×24 | (FC+12+12) | 18~36 | 6V×43 | (/1×7+3/+15+18) | 38~58 | ||
Compacted Strand Wire Rope | |||||||
| Rope Type | Typical Construction | Rope Diameter(mm) | Rope Type | Typical Construction | Rope Diameter(mm) | ||
| Wire Rope | Strand | Wire Rope | Strand | ||||
| 6×K7 | 6×K7 | 1+6 | 10~40 | 8×K36-PWRC(K) | 8×K36WS-PWRC(K) | 1+7+7/7+14 | 22~60 |
| 6×K19 | 6×K19S | 1+9+9 | 12~40 | 15×K7 | 15×K7 | 1+6 | 22~60 |
| 6×K26WS | 1+5+5/5+10 | 14~40 | 16×K7 | 16×K7 | 1+6 | 22~60 | |
| 6×K31WS | 1+6+6/6+12 | 16~40 | 18×K7 | 18×K7 | 1+6 | 14~48 | |
| 6×K36 | 6×K36WS | 1+7+7/7+14 | 24~68 | 18×K9 | 18×K9S | 1+9+9 | 24~60 |
| 6×K41WS | 1+8+8/8+16 | 38~68 | 35W×K7 | 35W×K7 | 1+6 | 14~42 | |
| 8×K19 | 8×K17S | 1+8+8 | 16~38 | 35W×K19S | 1+9+9 | 35~52 | |
| 8×K19S | 1+9+9 | 16~40 | 35W×K26WS | 1+5+5/5+10 | 40~60 | ||
| 8×K26WS | 1+5+5/5+10 | 20~42 | AL·1618K | AL·1618K | 1+6 | 18~60 | |
| 8×K31WS | 1+6+6/6+12 | 24~50 | AL·1710K | AL·1710K26WS | 1+5+5/5+10 | 20~50 | |
| 8×K36 | 8×K36WS | 1+7+7/7+14 | 28~78 | AL·1710K31WS | 1+6+6/6+12 | 20~50 | |
| 8×K41WS | 1+8+8/8+16 | 30~78 | AL·1710K36WS | 1+7+7/7+14 | 30~50 | ||
| 8×K19-PWRC(K) | 8×K19S-PWRC(K) | 1+9+9 | 20~48 | AL·1712K | AL·1712K7 | 1+6 | 20~40 |
| 8×K26WS-PWRC(K) | 1+5+5/5+10 | 20~48 | AL·1710K719S | 1+9+9 | 30~60 | ||
| 8×K31WS-PWRC(K) | 1+6+6/6+12 | 20~56 | |||||
Steel Cable | |||||||
| Rope Type | Typical Construction | Rope Diameter(mm) | Rope Type | Typical Construction | Rope Diameter(mm) | ||
| Wire Rope | Strand | Wire Rope | Strand | ||||
| 7×[6×37(a)+IWR] | 6×[6×36WS+IWR]+IWRC | 192~260 | 9×[6×37(a)+IWR] | 8×[6×36WS+IWR]+IWRC | 192~260 | ||
| 6×[6×41WS+IWR]+IWRC | 192~260 | 8×[6×41WS+IWR]+IWRC | 192~260 | ||||
| 6×[6×49SWS+IWR]+IWRC | 192~260 | 8×[6×49SWS+IWR]+IWRC | 192~260 | ||||
| 7×[6×61(a)+IWR] | 6×[6×55SWS+IWR]+IWRC | 192~260 | 9×[6×61(a)+IWR] | 8×[6×55SWS+IWR]+IWRC | 192~260 | ||
| 6×[6×61FWS+IWR]+IWRC | 192~260 | 8×[6×61FWS+IWR]+IWRC | 192~260 | ||||
| 6×[6×64SFS+IWR]+IWRC | 192~260 | 6×[6×64SFS+IWR]+IWRC | 192~260 | ||||
| 7×[6×37(b)+IWR] | 6×[6×37+IWR]+IWRC | 192~260 | 9×[6×37(b)+IWR] | 8×[6×37+IWR]+IWRC | 192~260 | ||
| 7×[6×61(b)+IWR] | 6×[6×61+IWR]+IWRC | 192~260 | 9×[6×61(b)+IWR] | 8×[6×61+IWR]+IWRC | 192~260 | ||
